Mitsubishi CM400HC6-24NFM 1200V 400A IGBT Power Module

Mitsubishi CM400HC6-24NFM 1200V 400A IGBT Power Module Specification

Components
Dual IGBT with Fast Recovery Freewheel Diodes

Usage
Industrial Power Control

Output
AC Switching Output

Power Supply
DC

Input
DC Input

Power Rating
Approx. 480 kW

Product Type
IGBT Power Module

Application
Variable Frequency Drives (VFDs), Servo Drives, UPS Systems, Renewable Energy Inverters, Welding Machines, Industrial Automation

Rated Voltage
1200 Volt (V)

Supply Voltage
1200 Volt (v)

Dimension (L*W*H)
Approx. 140 x 100 x 30 Millimeter (mm)

Function
High-Speed Power Switching

Color
Black

Weight
1.2 Kilograms (kg)

Warranty
30

Phase
Three Phase

Features
Low Conduction Loss, Fast Switching Speed, High Efficiency, High Reliability, Excellent Thermal Performance, Compact Design

Thickness
30 Millimeter (mm)

Current Rating
400 Ampere (A)

Mitsubishi CM400HC6-24NFM 1200V 400A IGBT Power Module Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About Mitsubishi CM400HC6-24NFM 1200V 400A IGBT Power Module

The Mitsubishi CM400HC6-24NFM IGBT Power Module is a 1200V, 400A high-performance insulated power module designed for high-frequency switching applications. It delivers low switching losses, high efficiency, and excellent thermal performance for industrial inverters, induction heating systems, and motor drives.

Product Name: Mitsubishi CM400HC6-24NFM IGBT Power Module
Brand: Mitsubishi Electric
Model: CM400HC6-24NFM
Product Type: Single IGBT Power Module
Configuration: Single IGBT with SiC Freewheel Diode
Collector-Emitter Voltage (VCES): 1200 V
Collector Current (IC): 400 A
Pulse Collector Current: 800 A
Gate-Emitter Voltage (VGES): 20 V
Power Dissipation: 2715 W

High-Efficiency Industrial Power Switching

Designed with advanced IGBT technology, the CM400HC6-24NFM achieves high efficiency and reliability under heavy industrial loads. Its excellent thermal performance and low conduction loss make it suitable for applications requiring fast and consistent power switching while maintaining system stability.

Versatile Application Across Industries

The module serves critical roles in variable frequency drives, servo drives, UPS systems, and renewable energy inverters. Its robust performance and compact form factor enable integration into a variety of industrial automation and power control setups, optimizing productivity and energy management.

FAQ's of Mitsubishi CM400HC6-24NFM 1200V 400A IGBT Power Module:

Q: How is the Mitsubishi CM400HC6-24NFM IGBT power module typically used in industrial applications?

A: The CM400HC6-24NFM is primarily used for efficient power switching in industrial systems like variable frequency drives (VFDs), servo drives, uninterruptible power supplies (UPS), welding machines, and renewable energy inverters. It helps regulate and convert electrical energy with high-speed switching and reliability.

Q: What are the main benefits of using this IGBT power module?

A: This power module offers several benefits including high efficiency, fast switching, low conduction loss, superior thermal performance, high reliability, and a compact design. These features contribute to improved system performance and lower operational costs in industrial environments.

Q: When should I consider replacing or servicing the CM400HC6-24NFM module?

A: You should consider replacement or maintenance if you detect abnormal heating, erratic switching behavior, or physical damage. Regular inspection is recommended in high-load environments to maintain optimum performance and prevent unexpected system failures.

Q: Where can the CM400HC6-24NFM be installed within industrial systems?

A: This module is designed for installation within power cabinets or control systems that manage AC switching for motors, energy storage, or automation systems. Its compact size (140 x 100 x 30 mm) allows it to fit in space-constrained or modular cabinet designs.

Q: What is the process for integrating this module into a power control setup?

A: Integration typically involves mounting the module, ensuring proper heat dissipation, connecting DC power input, and interfacing with the load for AC output. It is recommended to follow manufacturer guidelines for electrical connections and system configuration to achieve safe operation.

Q: How does the CM400HC6-24NFM improve the efficiency and reliability of power conversion systems?

A: The module's dual IGBT with fast recovery freewheel diodes ensures rapid and efficient energy switching, reduces losses, and supports a stable power supply. Its excellent thermal management further enhances long-term reliability and operational uptime in demanding applications.
