Infineon TT330N16KOF Dual Thyristor Module

Infineon TT330N16KOF Dual Thyristor Module Specification

Operating Temperature
-40 C to +125 C Celsius (oC)

Output
Controlled AC/DC Output

Input
AC Input

IP Rating
IP00

Components
Dual Thyristor

Usage
Industrial Power Control

Power Supply
AC/DC

Product Type
Dual Thyristor Module

Power Rating
Approx. 530 kW

Application
Motor Drives, Soft Starters, DC Drives, Industrial Rectifiers, Power Controllers, UPS Systems

Rated Voltage
1600 Volt (V)

Supply Voltage
1600 Volt (v)

Dimension (L*W*H)
Approx. 115 x 50 x 30 Millimeter (mm)

Function
Power Switching & AC Control

Color
Black

Weight
Approx. 1.5 Kilograms (kg)

Warranty
1 Year

Usage & Applications
Soft Starters, AC/DC Motor Drives, Industrial Rectifiers, Power Supplies, Welding Equipment, Induction Heating Systems

Phase
Three Phase

Material
Copper Base Plate, Ceramic Insulation, Silicon Semiconductor

Features
High Surge Current Capacity, Low On-State Loss, High Reliability, Compact Design, Excellent Thermal Performance

Thickness
Approx. 30 Millimeter (mm)

Current Rating
330 A

Frequency
50/60 Hertz (HZ)

Infineon TT330N16KOF Dual Thyristor Module Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About Infineon TT330N16KOF Dual Thyristor Module

The TT330N16KOF Thyristor Power Module offers high efficiency, long operating life, and dependable switching performance. Its compact screw-mount design ensures easy installation in industrial automation, AC/DC converters, soft starters, and heavy-duty power supplies.

Product Name: Infineon TT330N16KOF Dual Thyristor Power Module
Brand: Infineon (Eupec)
Product Type: Thyristor Power Module
Model: TT330N16KOF
Configuration: Dual Thyristor
Voltage Rating: 1600 V
Average Current: 330 A
RMS Current: 520 A
Gate Trigger Current: 200 mA
Holding Current: 300 mA
Technology: Silicon (Si)
Mounting Type: Screw Mount
Package Type: Isolated Module

Engineered for Performance

Infineon's TT330N16KOF Dual Thyristor Module offers unmatched power handling in a compact form. Designed for industrial use, it handles up to 530 kW and is built to deliver stable performance in high-demand environments such as motor drives, soft starters, and industrial rectifiers.

Advanced Features and Construction

This module features a copper base plate for superior heat dissipation, ceramic insulation for electrical safety, and silicon semiconductors for high efficiency. Its design ensures high surge current capacity, low on-state losses, and enhanced reliability, even during prolonged, intense operation.

Versatile Industrial Applications

Whether used in AC/DC drives, power controllers, or welding equipment, the TT330N16KOF adapts seamlessly to various industrial power control needs. Its three-phase compatibility, wide operating temperature, and controlled AC/DC output make it a versatile solution for modern power systems.

FAQ's of Infineon TT330N16KOF Dual Thyristor Module:

Q: How is the Infineon TT330N16KOF Dual Thyristor Module used in industrial applications?

A: The TT330N16KOF is typically employed in motor drives, soft starters, rectifiers, and power controllers. Its high current and voltage ratings, along with robust thermal properties, allow it to manage the switching and control demands of industrial power systems efficiently.

Q: What benefits does the compact design of this module offer?

A: The module's compact dimensions (approx. 115 x 50 x 30 mm) ensure easy integration into existing equipment, saving valuable space in control panels while maintaining high power handling capabilities and superior reliability.

Q: Where can the TT330N16KOF module be installed?

A: It can be installed in a wide range of industrial environments, including factories utilizing AC/DC motor drives, industrial rectifiers, power supplies, and welding or induction heating systems, provided the environment is compatible with its IP00 rating.

Q: When should I consider using this thyristor module for my project?

A: Choose this module when your application requires high surge current capacity, precise AC/DC control, and high reliability under challenging thermal conditions-such as in demanding motor control or power conversion setups.

Q: What process ensures the safe operation of this module?

A: Proper mounting on a heat sink, ensuring secure electrical connections, and maintaining operation within the specified temperature and current limits are essential processes for reliable and safe use.

Q: How does the module handle thermal management during high power operation?

A: The TT330N16KOF features a copper base plate and ceramic insulation, which provide outstanding heat dissipation and insulation stability-helping the module maintain excellent performance even under continuous, high-stress conditions.
