6ES7131-6FD01-0BB1 Digital Input Module

6ES7131-6FD01-0BB1 Digital Input Module Specification

Sensors Specification
For use with standard 24V sensors

Components
Terminal block not included

Power Source
Bus-powered

Input
16 digital inputs

Features
Hot swapping, compact design, module diagnostics

Display Type
Status LEDs

Power Supply
From Backplane Bus

Operating Temperature
-30 C to +60 C

IP Rating
IP20

Response Time
<0.2 ms

Usage
Industrial Automation, PLC Systems

Interface
ET 200SP Backplane Bus

Resolution
Digital (Binary 0/1)

Product Type
Digital Input Module

Application
SIMATIC ET 200SP Distributed I/O

Rated Voltage
24 V DC

Supply Voltage
24 V DC

Size
Standard ET200SP module size

Function
Digital Input Module for processing digital signals

Color
Grey/Black

Weight
Approx. 50 g

Capacity
16 channels

Thickness
Compact module

Current Rating
Approx. 6 mA per channel

Frequency
DC

Wiring Method
With BU-type base units (not included)

Isolation
Yes, between channels and backplane

Module Type
DI 16x24VDC High Feature

Signal Type
PNP (positive logic)

Order Number
6ES7131-6FD01-0BB1

Mounting Type
DIN-rail mounting

Housing Material
Plastic

Module Width
15 mm

Diagnosis Functions
Yes (short circuit, wire break)

Relative Humidity
5% to 95%, non-condensing

Series
SIMATIC ET 200SP

Number of Modules per Station
Up to 64 modules

Permissible Cable Length
600 m (shielded), 300 m (unshielded)

6ES7131-6FD01-0BB1 Digital Input Module Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal

Supply Ability
12 Pieces Per Month

Delivery Time
2 Week

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 6ES7131-6FD01-0BB1 Digital Input Module

The Siemens 6ES7131-6FD01-0BB1 is a high-performance digital input module designed for SIMATIC ET 200SP distributed I/O systems. It features 4 input channels supporting 120230V AC signals, making it ideal for reliable detection of field signals such as switches and sensors. With compact design, built-in diagnostics, and seamless integration with PROFINET systems, this module ensures efficient and stable industrial automation performance.

Specifications

Brand: Siemens

Model: 6ES7131-6FD01-0BB1

Series: SIMATIC ET 200SP

Product Type: Digital Input Module

Number of Inputs: 4 Channels

Input Voltage: 120230 V AC

Signal Type: Digital AC (IEC 61131 Type 3)

Frequency: 50/60 Hz

Diagnostics: LED status indicators, module diagnostics

Isolation: Yes

Communication: PROFINET (via interface module)

Mounting: DIN Rail (via Base Unit)

Protection Class: IP20

Standards: IEC 61131, CE, UL

Optimized for Industrial Automation

Engineered as part of the SIMATIC ET 200SP series, the 6ES7131-6FD01-0BB1 digital input module streamlines the connection of multiple field sensors. Its capability to manage 16 discrete input signals with high diagnostic features ensures consistent monitoring and rapid fault identification in complex automation layouts.

Flexible and Space-Saving Installation

With a compact 15 mm width and modular design, this module is perfectly suited for installations with limited cabinet space. DIN-rail mounting allows seamless integration into existing setups, while hot swapping reduces downtime by enabling module replacement without interrupting system operation.

FAQ's of 6ES7131-6FD01-0BB1 Digital Input Module:

Q: How do I install the 6ES7131-6FD01-0BB1 module in a SIMATIC ET 200SP system?

A: The module mounts directly onto a DIN rail and connects to the ET 200SP backplane bus via a BU-type base unit (not included). Ensure the power is off or use hot swapping if your system supports it, then snap the module in place and secure wiring according to the wiring diagram.

Q: What are the main benefits of this digital input module for automation projects?

A: Key advantages include high-density 16-input channels in a compact form factor, integrated diagnostics (such as short circuit and wire break detection), support for hot swapping, and reliable operation across a broad temperature range. These features enhance system reliability and minimize downtime.

Q: When should I use a PNP (positive logic) digital input module like this one?

A: Choose this PNP input module when interfacing with devices or sensors that output a positive voltage when active. This is common in most industrial 24V DC sensor configurations, ensuring compatibility with standard automation equipment.

Q: Where can I use the 6ES7131-6FD01-0BB1 digital input module?

A: This module is ideal for use in distributed I/O configurations within industrial environments, such as factory automation, process control stations, or machine building, where reliable 24V DC digital signal input is required.

Q: What is the process for diagnostic detection and indication on this module?

A: The module continuously monitors all input channels for issues like short circuits or wire breaks. When a fault is detected, the integrated status LEDs and system diagnostics provide instant notification, facilitating quick maintenance.

Q: Can this module support long cable runs and what are the permissible cable lengths?

A: Yes, it allows cable runs up to 600 meters (shielded) or 300 meters (unshielded), providing flexibility in distributed installations, especially across large factory floors or plant areas.

Q: What wiring components are required for installation?

A: You will need compatible BU-type base units and terminal blocks, which are not included with the module. Proper wiring must be done per the provided specifications to ensure safe and reliable operation.
