Siemens Simatic KTP-1500 Comfort HMI

Siemens Simatic KTP-1500 Comfort HMI Specification

Usage
Industrial automation, process monitoring, machine control

Power Supply
dc

IP Rating
IP65 (front), IP20 (back)

Input
Touch panel, USB, Ethernet, SD card slot

Operating Temperature
0C to +50C

Power Source
DC powered

Interface
Profinet, Profibus, Ethernet, USB 2.0

Output
Ethernet, USB, Audio output

Thermal Conductivity
Not specified by manufacturer

Components
Touch display, CPU, ports (USB/Ethernet/SD card), mounting hardware

Resolution
1366 x 768 pixels (HD) 16:9 format

Display Type
TFT LCD Touchscreen

Features
15-inch widescreen touch display, daylight readable, multi-lingual support, integrated USB, easy mounting, LED backlight, advanced diagnostics

Processor Speed
800 MHz

Response Time
10 ms (typical touch response)

Product Type
Touch Panel HMI

Application
Automated systems, manufacturing lines, plant control

Rated Voltage
24 Volt (V)

Supply Voltage
24 V DC

Size
15 inches

Dimension (L*W*H)
476 mm x 315 mm x 75 mm

Function
Human Machine Interface (HMI) for monitoring and controlling industrial processes

Color
gray

Weight
Approx. 5.7 kg

Warranty
1 YAER

Capacity
Internal RAM 24 MB, Flash 12 MB

Current Rating
Max. 1.1 A at 24 V DC

Thickness
75 mm (approx.)

Frequency
50-60 Hz

Display Colors
16 million colors

Mounting Type
Panel mounting

SD Card Slot
1 slot for memory expansion

Software Platform
WinCC Comfort (TIA Portal)

System Memory
512 MB RAM

Audio Interface
Speaker output on board

Firmware Update
Supported via USB or network

Flash Memory
512 MB

Backlight Lifetime
50,000 hours (typical)

Touch Technology
Analog resistive touch

Storage Temperature
-20C to +60C

Humidity
10% to 90% (non-condensing)

Communication Ports
2 x Ethernet (RJ45), 2 x USB, 1 x SD/SDHC card slot

Password Protection
User and access level-based

Vibration/Shock Resistance
IEC 60068-2-6/ IEC 60068-2-27 compliant

Real-Time Clock
Integrated, battery-backed

Siemens Simatic KTP-1500 Comfort HMI Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal

Supply Ability
12 Pieces Per Month

Delivery Time
1 Week

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About Siemens Simatic KTP-1500 Comfort HMI

The Siemens SIMATIC HMI TP1500 Comfort (6AV2124-0QC02-0AX1) is a 15.4-inch widescreen TFT touch panel with

pixel resolution, 16 million colors, PROFINET and MPI/PROFIBUS DP interfaces, 24 MB user memory, and WEC 2013 OS, designed for high-end visualization in industrial environments.

www.dacelsolutions.com

Key Technical Specifications (TP1500 Comfort)

Display: 15.4" TFT widescreen, 16M colors,

Operating System: Windows Embedded Compact 2013.

Memory: 24 MB configuration memory.

Interfaces: PROFINET (2 x RJ45), MPI/PROFIBUS DP, USB hosts.

Protection: IP65 (front), NEMA 4x.

Dimensions:

mm (cutout).

Voltage: 24 V DC

Intuitive Touch Operation

The KTP-1500 Comfort HMI incorporates a highly responsive analog resistive touch interface with a typical response time of 10 ms, allowing seamless machine control and real-time process monitoring. Its 15-inch widescreen display makes navigation and visualization of complex automation processes effortless, even under direct light.

Robust Industrial Build

Constructed with industrial-grade materials, the panel features IP65 front protection and compliance with IEC 60068-2-6 and 60068-2-27 for vibration and shock resistance. Operating comfortably in temperatures from 0C to +50C, and humidity up to 90%, it is engineered for demanding manufacturing and plant environments.

Flexible Connectivity and Expansion

Equipped with dual Ethernet ports, dual USB, and a dedicated SD/SDHC memory slot, the HMI supports extensive communication, easy data logging, and firmware upgrades. The panel's advanced features allow integration with Profinet, Profibus, and other networked automation systems via WinCC Comfort, enabling centralized or distributed control.

FAQ's of Siemens Simatic KTP-1500 Comfort HMI:

Q: How is the Siemens Simatic KTP-1500 Comfort HMI mounted?

A: The KTP-1500 Comfort HMI is designed for panel mounting, making it suitable for integration into control cabinets or system panels commonly found in industrial environments.

Q: What benefits does the analog resistive touch technology provide?

A: The analog resistive touch technology allows accurate and reliable input, even when operators wear gloves. Its robust construction ensures dependable operation in harsh and high-vibration conditions.

Q: When should I expand the HMI memory using the SD/SDHC card slot?

A: Memory expansion via the SD/SDHC card slot is recommended when your applications require more storage for project files, data logging, or firmware updates, ensuring smooth operation without internal storage limitations.

Q: Where can the HMI be installed in terms of environmental conditions?

A: The panel is suitable for installation in industrial setups where the temperature ranges from 0C to +50C, relative humidity is between 10% and 90% (non-condensing), and there is potential for exposure to vibration and minor shocks.

Q: What automation software is compatible with this HMI?

A: The KTP-1500 Comfort HMI is fully compatible with WinCC Comfort (TIA Portal), allowing users to efficiently design, monitor, and control industrial processes and manage system diagnostics.

Q: How do I perform firmware updates on the device?

A: Firmware updates for the KTP-1500 Comfort HMI can be carried out easily via USB ports or across the network, simplifying maintenance and functionality enhancements.
