SIEMENS 6AV2124-0MC01-0AX0 OPERATOR INTERFACE PANEL

SIEMENS 6AV2124-0MC01-0AX0 OPERATOR INTERFACE PANEL Specification

Operating Temperature
0 to +50C

IP Rating
Front: IP65, Rear: IP20

Processor Speed
800 MHz RISC CPU

Input
Ethernet, USB, SD card slot, 24 V DC power input

Response Time
Touch response < 1 s

Resolution
800 x 480 pixels (WVGA)

Features
7-inch touchscreen, high-resolution display, USB and Ethernet connectivity, Windows CE-based, LED backlighting, compact design

Output
Ethernet, USB

Power Source
External 24 V DC

Display Type
TFT LCD, 16 million colors

Power Supply
External 24 V DC supply

Interface
1x Ethernet (RJ45), 2x USB 2.0, 1x SD card slot

Components
Display, touch screen, CPU, communication ports, mounting hardware

Usage
Used in automation, manufacturing, and industrial control applications

Product Type
HMI (Human Machine Interface) Operator Panel

Application
Industrial automation and control

Rated Voltage
24 V DC

Supply Voltage
24 V DC (18-30 V allowable)

Size
7-inch widescreen

Dimension (L*W*H)
Width: 214 mm, Height: 158 mm, Depth: 56 mm

Function
Touchscreen operator interface for monitoring and controlling industrial processes

Color
Silver (front), black (edges and rear)

Weight
Approx. 1.12 kg

Capacity
No internal storage, supports external memory via SD card

Current Rating
Approx. 0.35 A at 24 V DC

Thickness
56 mm (panel depth)

Touch Screen Type
Analog-resistive

Front Panel Material
Aluminum and plastic

Backlight Type
LED

SD Card Support
Up to 32 GB

Vibration Resistance
1 mm (10-57 Hz), 0.7g (57-150 Hz) as per IEC 60068-2-6

Ambient Humidity
10-90% (non-condensing)

Mounting
Panel-mount

Communication Protocols
Profinet, Ethernet/IP, Modbus TCP/IP, TCP/IP, DHCP, HTTP, FTP

Life Expectancy (Backlight)
Approx. 50,000 hours at 25C

Flash Memory
12 MB (integrated for user data)

Software Compatibility
TIA Portal (WinCC Basic/Comfort/Advanced)

Shock Resistance
15 g, 11 ms per IEC 60068-2-27

Operating System
Siemens Windows CE

Language Support
Multi-language with Unicode

SIEMENS 6AV2124-0MC01-0AX0 OPERATOR INTERFACE PANEL Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal

Supply Ability
12 Pieces Per Month

Delivery Time
3 Week

Sample Available
No

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About SIEMENS 6AV2124-0MC01-0AX0 OPERATOR INTERFACE PANEL

Brand: Siemens
Model Number: 6AV2124-0MC01-0AX0
Product Type: HMI Operator Interface Panel
Series: SIMATIC HMI TP1200 Comfort
Display Size: 12.1 Inch Widescreen TFT
Resolution: 1280 800 Pixels
Display Colors: 16 Million Colors
Input Type: Touchscreen (Analog Resistive)
Operating System: Windows CE 6.0
Memory: 12 MB Configuration Memory
Communication Ports: PROFINET / Ethernet, MPI / PROFIBUS DP
Additional Interfaces: USB, SD Card Slots
Supply Voltage: 24 V DC (19.228.8 V)
Protection Class: IP65 (Front), IP20 (Rear)
Mounting Type: Panel Mount
Weight: Approx. 3.46 kg
Country of Origin: Germany

Versatile Industrial Control Interface

Engineered for automation and industrial control, the SIEMENS 6AV2124-0MC01-0AX0 provides user-friendly monitoring and process management. Its 7-inch touchscreen offers responsive operation and high-resolution WVGA graphics. The device is fully compatible with TIA Portal and supports multi-language configuration for global operations.

Durable and Reliable Design

Constructed with a rugged aluminum and plastic front panel, this operator interface panel provides IP65 protection on the front, safeguarding against dust and water. Its backlight lasts up to 50,000 hours at standard temperature, ensuring enduring performance in demanding industrial settings.

Multiple Connectivity Options

The panel is equipped with Ethernet, USB 2.0, and SD card interfaces, allowing seamless data transfer, flexible network integration, and expandable storage up to 32 GB. This versatility is ideal for managing process data or firmware updates efficiently.

FAQ's of SIEMENS 6AV2124-0MC01-0AX0 OPERATOR INTERFACE PANEL:

Q: How is the SIEMENS 6AV2124-0MC01-0AX0 panel typically installed?

A: This operator interface panel is designed for panel-mounting, fitting securely into industrial control cabinets or operator consoles. The mounting hardware included ensures stable and easy installation in your automation setup.

Q: What environments is this HMI suitable for, considering humidity and temperature?

A: It operates effectively in ambient humidity levels from 10% to 90% (non-condensing) and in temperatures ranging from 0C to +50C, making it ideal for a wide range of industrial and manufacturing environments.

Q: What are the benefits of its analog-resistive touch screen and LED backlighting?

A: The analog-resistive touchscreen enables precise, glove-friendly operation in industrial settings. The LED backlight provides long life (approx. 50,000 hours), ensuring consistent visibility and minimal maintenance needs.

Q: What communication protocols does the panel support for integration?

A: It supports Profinet, Ethernet/IP, Modbus TCP/IP, TCP/IP, DHCP, HTTP, and FTP. This enables integration into various network architectures and compatibility with numerous industrial controllers and systems.

Q: How does the panel handle data storage and expansion?

A: It features 12 MB internal memory for user data and supports external SD cards up to 32 GB, allowing flexible storage capacity for applications, project files, or data logging needs.

Q: When should you consider using this HMI panel in your application?

A: This panel is recommended for use in industrial automation, manufacturing, and process control where reliable, multi-protocol connectivity and a user-friendly touchscreen interface are required.

Q: What makes this HMI panel beneficial for multilingual or international operations?

A: With Unicode support and multi-language functionality, the panel facilitates efficient operation in diverse settings, supporting global teams and integration into international manufacturing environments.
